| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
| LED Indicator | 9 × Link/Ack LED indicators, 1 × Power LED indicator |
| Interfaces | 8 × 10/100 Base-TX Ethernet ports (Data/Power), 1 × 10/100 Base-TX Ethernet port (Data) |
| Transmission Media | Recommended: CAT5/5e UTP or better |
| Fan Quantity | N/A |
| Dimension | 177.5mm × 104.0mm × 26.0mm |
| Level of Protection | Lightning protection for ports: 6KV
Lightning protection for power: 4KV
ESD: Air discharge: ±10kV
Contact discharge: ±8kV |
| Forwarding Mode | Store-and-forward |
| Switch Capacity | 1.8 Gbit/s |
| Packet Forwarding Rate | 1.34 Mpps |
| Buffer | 1.25 Mb |
| MAC Address Table | 4K |
| Jumbo Frame | N/A |
| PoE Budget | Single port: AF: 15.4W, AT: 30W
Whole device: 58W |
| Power Consumption | / |
| Input Voltage | 100－240V AC 50/60Hz, 51V / 1.25A DC (Power Adapter) |
| Mounting | Desktop mounting: supportWall mounting: supportRack mounting: non-support |
| Operating Temperature | 0℃ ~ 45℃ |
| Storage Temperature | -40℃ ~ 70℃ |
| Operating Humidity | 10% ~ 90% non-condensing |
| Storage Humidity | 5% ~ 90% non-condensing |
