| Standard & Protocol | IEEE802.3, IEEE802.3u, IEEE802.3ab |
| Interfaces | 1 × 10/100Mbps WAN port
3 × 10/100Mbps LAN ports |
| Antenna | 2 × 5dBi external antennas |
| Button | 1 × RST |
| Power | Input: AC 100-240V~ 50/60Hz 0.6A
Output: DC 9V ⎓ 0.6A |
| Dimension | 127.4 × 90.5 × 26mm |
| LED Indicator | SYS, WLAN 1, 2, 3, WAN |
| Wireless Standard | IEEE 802.11b/g/n @2.4GHz |
| Data Rate | 2.4GHz: Up to 300Mbps |
| Frequency | 2.4GHz |
| Transmission Power | CE: |
| Basic Features | WiFi On/Off |
| Wireless Security | WPA/WPA2, WPA-PSK/WPA2-PSK |
| Internet Connection Type | PPPoE, Dynamic IP, Static IP
PPPoE (Russia), PPTP (Russia), L2TP (Russia) |
| Operating Mode | Wireless Router Mode, Universal Repeater Mode |
| Special Features | Smart WiFi Schedule |
| Temperature | Operating: 0℃ ~ 40℃
Storage: -40℃ ~ 70℃ |
