| Network Standards | IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab |
| LED Indicator | 1 * Power8 * Link/Act |
| Interfaces | 8 * 10/100/1000 Base-T Ethernet ports (Auto MDI/MDIX) |
| Transmission Media | Recommended: CAT5/5e UTP or better |
| Dimensions | 124mm x 59mm x 23mm |
| Material | Plastic |
| Level of Protection | ESD: Air discharge: ±8kV
Contact discharge: ±6kV |
| Forwarding Mode | Store-and-forward |
| Switch Capacity | 16 Gbps |
| Packet Forwarding Rate | 12.00 Mpps |
| Buffer | 4 Mb |
| MAC Address Table | 8K |
| Power | Input: 100-240V AC 50/60Hz
Output: 5V 0.6A (External power adapter) |
| Power Consumption | Max: |
| Mounting | Desktop mounting: support
Wall mounting: support
Rack mounting: non-support |
| Environment | Operating temperature: 0°C - 45°C
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%) RH, non-condensing
Storage humidity: (5% - 90%) RH, non-condensing |
| Certification | CE, FCC, RoHS |
| Protocols | CDMA/CD |
| MAC Address Learning | Auto-Learning and Auto-Aging |
| Functions | Plug-and-play |
