| Processor | Embedded MCU Processor |
| Operation System | Embedded Linux Operation System |
| Display Resolution | 1024 × 600 |
| Display Screen | 7-inch colorful TFT screen |
| Audio Compression Rate | 64 Kbps |
| Audio Compression Standard | G.711 U |
| Audio Input | Built-in omnidirectional microphone |
| Audio Output | Built-in loudspeaker |
| Audio Quality | Noise suppression and echo cancellation |
| Ethernet | 10/100 Mbps Self-Adaptive Ethernet |
| Network Protocol | TCP/IP, RTSP |
| I/O Input | 4 |
| I/O Output | 2 |
| Power Supply | 12 VDC/PoE (IEEE 802.3af) |
| Power Consumption | ≤10 W |
| Working Temperature | -40° C to +60° C (-40° F to 140° F) |
| Working Humidity | 10% to 95% |
| Dimension (L × W × D) | 200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6") |
| Weight (with packaging) | 683 g |
| Weight (without packaging) | 355 g |
| IP Protection Level | IP65 |
| Memory | 128 MB |
| Dimensions (L × W × H) | 98 mm × 99.8 mm × 43.9 mm (3.86" × 3.93" × 1.73") |
