| Screen size | 4.3 inch |
| Operation method | Capacitive touch screen |
| Type | LCD |
| Lens | 2 |
| Resolution | 2 MP |
| Audio quality | Noise suppression and echo cancellation |
| Wired network | Supported |
| Wi-Fi | Supported, 2.4 G, 802.11b/g/n |
| Network interface | 1 RJ-45, 10/100 M self-adaptive |
| Lock control | 1 |
| Exit button | 1 |
| Door contact input | 1 |
| TAMPER | 1 |
| RS-485 | 1 RS-485 (Half duplex, HIKVISION) |
| Wiegand | 1 Wiegand (Hik 26bit, Hik 34bit) |
| USB | 1 |
| Card type | EM card |
| Card reading frequency | 125 KHz |
| Power supply | 12 VDC, 1 A (power adapter included) |
| Working temperature | -10 °C to 40 °C (14 °F to 104 °F) |
| Working humidity | 0 to 90% (No condensing) |
| Dimensions | 118.4 mm × 118.4 mm × 21.8 mm (4.66" × 4.66" × 0.86") |
| Installation | Wall mounting, base mounting |
| Weight | Gross weight: 0.71 kg (1.57 lb), Net weight: 0.23 kg (0.51 lb) |
| Language | English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean, Japanese |
| Platform | Hik-ProConnect and HikCentral Professional |
| Face anti-spoofing | Supported |
