| Wireless IPC Access Capability | 5MP * 8 |
| Wired IPC Access Capability | 5MP * 8 |
| Antenna Number | 2 |
| Maximum Wireless Range | 100 m |
| Radio Frequency | 2.4G |
| Ethernet Port | One 10/100M adaptable Ethernet interface |
| Required Access Bandwidth | 100 Mbps |
| VGA Video Output | 1 channel, resolution up to 1920×1080/60Hz |
| HDMI Video Output | 1 channel, resolution up to 2560×1440/30Hz |
| Recording Resolution | 5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/2CIF/CIF/QCIF |
| Video Compression | H.265, H.264 |
| Decode Playback | Supports 8 * 5MP |
| Video Recording Modes |
Manual recording, motion detection, scheduled, and event-triggered recording |
| Backup Options | Hard disk backup, Internet application backup |
| Playback Modes | Instant, normal, event, tag, log event playback |
| Open Protocol Support | Yes |
| HDD Interface | One built-in SATA port |
| HDD Capacity | Supports 1TB to 8TB 3.5-inch HDD |
| Audio Input/Output | Not supported |
| Hardware Reset | Supports |
| USB 2.0 Interface | 1 |
| Product Dimensions | 235 mm × 270 mm × 44.5 mm |
| Packaging Dimensions | 387 mm × 362 mm × 75 mm |
| Net Weight | 1KG |
