Cylinder Quantity | Single cylinder |
Finish | Nickel Plating |
Body Material | Stainless Steel |
Thickness of Lock Body | 2.0 mm |
Keys | 5 pcs brass standard keys |
Extension Length | 20 mm of deadbolt |
Door Thickness | 35 mm ~ 50 mm |
Working Voltage | 9 ~ 18 VDC |
Working Current | 350 mA |
Static Current | 15 mA |
Locking Method | By collision |
Lock-Opening Delay Time | Automatically lock within 9s if not opened |
Operating Time | 0.5 s |
Service Life | 500,000 times |
Regulated & Filtered | 500 VDC Voltage |
Locking Method (Magnetic) | Magnetic induction |
Surface Temp | Low temperature |
Advantage | Low noise, low consumption, long life |
Holding Force | 1000 kg |
Open Ways from Outside | Keys |
Open Ways from Inside | Rotary knob |
Suitable Humidity | 0-90% (non-condensing) |
Operating Temperature | -40°C ~ 50°C |
