| Collinear Load Test | 600/1200 pounds |
| Reverse Current Protection | MOV (Metal Oxide Varistor) |
| LED Indicator | Indicates the Power Status |
| Material | High Strength Material with Anodized Aluminum Housing |
| Anti-Residual Magnetism | Yes, Anti-Residual Magnesium Design |
| Holding Force | 280 KG (600 lbs) |
| Dimension | 250 x 48 x 27 mm |
| Armature Plate | 180 L x 38 W x 11 H (mm) |
| Voltage | 12V/24V/48V DC ±10% |
| Current | 0.48A/0.24A |
| Operating Temperature | -20°C to 60°C |
| Working Mode | Power Off to Open (Normally Closed, NC) |
| Finish - Shell | Anodized Aluminum |
| Finish - Magnetic | Zinc |
| Finish - Armature | Zinc |
