| Feature | Description |
| Ports | 8 Port PoE Switch, Support One key Extend, ports 1-8 support 250 effective meters (Cat.5 or above) |
| VLAN Support | Support One key VLAN, ports 1-8 isolation for network security |
| Power Detection | Support standard IEEE 802.3af/at protocol, automatically detect and identify the PD devices comply with IEEE 802.3 af/at protocol and supply power. |
| Auto MDI/MDIX | Support upward port auto MDI/MDIX. |
| Switching System | Adopted storage forward switching system. |
| Smart Power | Smart power and minimum consumption, guarantee PD requirement. |
| Protection | Power supply circuit protection function and protection back-end device safety. |
| Adaptive Devices | Automatically provide the adaptive device. |
| Fanless Design | Fanless design realizes saving energy and environmental protection. |
| Compact Size | Compact size design. |
| Power Saving | Support saving power function when port disconnection. |
| Wire-Speed Forwarding | All Ports support Wire-speed forwarding capability. |
| Plug and Play | Plug and play, easy using without configuration. |
| Power Light | Power Indicator |
| PoE Indicator | PoE Power Indicator |
| Link/ACT Indicator | PD Devices Connected Indication |
| Mode | Description |
| AI VLAN Mode | In AI VLAN mode, ports 1-8 are isolated from each other, which can effectively restrain network storms and improve network performance. |
| AI Extend Mode | In AI Extend mode, the effective transmission distance of ports 1-8 can reach 250 meters, which is suitable for remote monitoring and power supply. |
| AI PoE Mode | In AI PoE mode, the switch automatically detects the working status of the PD device and automatically restarts the device if abnormal. |
| AI QoS Mode | In AI QoS mode, the video data will be processed preferentially when the device is congested to ensure smooth video. |
| Protocol Standard | IEEE 802.3 af/at |
| Description | Automatically detect and identify the PD devices and supply power, therefore, don’t worry about PoE or non-PoE devices that can damage private standards. |
