CP-Plus CCTV Power Supply Premium 8ch Metal 12v/10a (MD100P)

Product Dispatch within 24-96 Hours

₹700.00

(All Inclusive Taxes)

Product CodeG2097
BrandCP PLUS

Cash on Delivery (COD) facility is now available.
ModelCP-DPS-MD100P-12D
Warranty2 Years from CPPLUS Service Center
Product URLhttps://www.cpplusworld.com/cp-dps-md100p-12d

Power your surveillance system with the CPplus MD100P 8CH Metal Power Supply. This reliable CCTV power supply provides a stable 12V 10A output, perfect for powering up to 8 CCTV cameras. Built with high-quality components, this durable metal casing power supply ensures long-lasting performance and reliability for your security system. As a cost-effective solution for businesses, the MD100P offers exceptional value. Get the best price on this 8CH Metal Power Supply from Golchha Computer Rajasthan Online Store – your source for top-quality CCTV accessories at wholesale rates. Ideal for installers and security system integrators, this power supply is a must-have for any professional security setup. This high-quality CCTV accessory is perfect for powering your surveillance system, delivering consistent power to your cameras for optimal performance. Benefit from the peace of mind that comes with a reliable power supply – ensuring your security system is always running smoothly. Looking for bulk discounts on high-quality surveillance system power supplies? Contact us today to discuss your business requirements and receive a customized quote. Secure your system and your bottom line with the CPplus MD100P – the ideal 12V 10A Power Supply for your security needs. Order now or contact us for special pricing on large orders.

FeatureSpecification
Input Voltage180~264VAC
Output Voltage12V DC
Current Range0~10A
Rated Power120W
Ripple & Noise (max.)100mVp-p
Voltage Adjustment Range11.4~13.2V
Line Regulation1.0%
Voltage Tolerance2.0%
Setup Rise Time600ms, 30ms at full load
Hold Up Time (Typ.)13ms at full load
Load Regulation5.0%
Temperature Coefficient0.03%/°C (0~50°C)
Frequency Range47~63Hz
Efficiency (Typ.)84%
AC Current (Typ.)5A/115VAC, 3A/230VAC
Inrush Current (Typ.)20A/115VAC, 40A/230VAC
Leakage Current<2mA / 240VAC
Over Load110~200% rated output power, Protection type: Shut down O/P, re-power
Isolation ResistanceI/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC / 25°C/ 70% RH
Working Humidity20~90% RH Non-condensing
Vibration10 ~ 500Hz, 3G 10min./1 cycle, 60min.each along X, Y, Z axes
Dimension187(L) x 103(W) x 52mm(H)
Storage Temperature-20~+85°C, 10~95%RH
Working Temperature-20~+40°C
Withstand VoltageI/P-O/P: 1.5KVAC, I/P-FG: 1.5KVAC, O/P-FG: 0.5KVAC
