| Software Features | Scenario Setting | By alarm, by operation, by fault, by schedule, by manual |
| Learning Button | 1, for register |
| Hardware Features | Serial Port | 1, for debug |
| Electrical Characteristics | Power Supply | DC 7V to 24V |
| Operation Humidity | 10% to 90% |
| Operation Temperature | -10°C to 55°C |
| Wireless Transmission | RF Frequency | 433 MHz |
| RF Method | Two-way communication |
| RF Modulation | 2GFSK |
| RF Distance | 800 m |
| Wireless Security | AES-128 |
| Display | LEDs Status | 3, register/signal (green/red), power (green), relay status (blue) |
| Alarm Input | 1 for tamper, NO/NC |
| General | Installation Method | Wall-Mounting |
| Dimension (WxHxD) | 38 mm × 25 mm × 18 mm |
| Shell Material | Plastic |
| Color | White |
| Weight | 28.5 g |
| Device Management | Relay Output | 1, NO/NC (0 to 36V DC, Max 5A) |
