| Attribute | Details |
|---|
| Camera Type | PTZ |
| Image Sensor | 1/2.8" progressive scan CMOS |
| Max. Resolution | 1920 × 1080 |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux@(F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/1 s to 1/30000 s |
| Day & Night | IR cut filter |
| Zoom | 32x optical, 16x digital |
| Slow Shutter | Yes |
| DORI | Detect (25px/m): 2046.9 m, Observe (63px/m): 812.3 m, Recognize (125px/m): 409.4 m, Identify (250px/m): 204.7 m |
| Lens Focal Length | 4.8 mm to 153 mm |
| FOV | Horizontal: 50.8° to 2.6°, Vertical: 29.4° to 1.5°, Diagonal: 57.4° to 3° |
| Focus | Auto, semi-auto, manual |
| Aperture | Max. F1.6 |
| Zoom Speed | Approx. 4.8 s |
| Supplement Light Type | IR |
| Supplement Light Range | IR Distance: up to 200 m |
| PTZ Movement Range (Pan) | 360° |
| PTZ Movement Range (Tilt) | -15° to 90° (auto flip) |
| Pan Speed | Configurable from 0.1° to 160°/s; preset speed: 240°/s |
| Tilt Speed | Configurable from 0.1° to 120°/s, preset speed: 200°/s |
| Proportional Pan | Yes |
| Presets | 300 |
| Preset Freezing | Yes |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans |
| Park Action | Preset, pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan |
| 3D Positioning | Yes |
| PTZ Status Display | Yes |
| Scheduled Task | Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output |
| Power-off Memory | Yes |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third Stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 kbps to 16384 kbps |
| Audio Compression | G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM |
| Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)/16-64 Kbps (AAC) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/48 kHz |
| Network Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| Simultaneous Live View | Up to 20 channels |
| API | Open Network Video Interface (Version 19.12), ISAPI, SDK, ISUP |
| Security | Password protection, HTTPS encryption, 802.1X authentication, watermark, IP address filter, etc. |
| Network Storage | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Web Browser | IE11, Chrome 57+, Firefox 52+, Safari 11+ |
| Image Settings | Saturation, brightness, contrast, sharpness, gain, white balance adjustable |
| Image Enhancement | BLC, HLC, 3D DNR |
| Privacy Mask | 24 programmable polygon privacy masks |
| Interface | 1 RJ45 10M/100M Ethernet port |
| Alarm Inputs | 2 inputs, 1 output |
| Power Supply | 24 VAC, max. 42 W (including IR and heater); Hi-PoE |
| Dimension | Ø 220 mm × 363.3 mm |
| Weight | Approx. 5 kg |
| Material | ADC12 |
| Operating Condition | -30 °C to 65 °C, Humidity 90% or less |
| Protection | IP66, IK10, TVS 6000V lightning protection |
