| Model | ASUS B650 Series (AM5) |
| CPU | AMD Socket AM5 for Ryzen™ 9000/8000/7000 Series |
| Chipset | AMD B650 |
| Memory | 2 x DDR5 DIMM (Max 96GB), up to 8000+ MT/s (OC), Dual Channel, ECC/Non-ECC, EXPO |
| Graphics | 1 x HDMI 2.1 (Supports 4K@60Hz) |
| Audio | Realtek 7.1 HD Audio, 24-bit/192kHz, Audio Shielding |
| LAN | Realtek 2.5Gb Ethernet |
| Wi-Fi / Bluetooth | Wi-Fi 6, Bluetooth 5.3 |
| PCIe Slots | Ryzen 9000/7000: 1 x PCIe 4.0 x16 (x16 mode)
Ryzen 8000: 1 x PCIe 4.0 x16 (x8/x4 mode)
Chipset: 1 x PCIe 4.0 x16 (x4 mode) |
| Storage | 2 x M.2 Slots (PCIe 5.0/4.0)
4 x SATA 6Gb/s
Supports RAID 0/1/10 |
| USB (Rear) | 2 x USB 10Gbps (Type-A), 2 x USB 5Gbps, 4 x USB 2.0 |
| USB (Front Headers) | 1 x USB 5Gbps Type-C
1 x USB 5Gbps header (2 ports)
2 x USB 2.0 headers (4 ports) |
| Internal Connectors | 1 x 24-pin ATX, 1 x 8-pin CPU
2 x M.2, 4 x SATA
3 x ARGB headers, Clear CMOS, COM, S/PDIF, Front Audio, System Panel |
| Back Panel | USB (8 total), HDMI, Wi-Fi, Ethernet, Audio jacks |
