| Form 'A' Alarm Contact and Tamper Switch | Yes |
| Digital Signal Analysis | Ensures precise detection and reduces false alarms |
| Slim Profile Design | Compact design, ideal for residential use |
| ABS Plastic Construction | Offers shock and impact protection |
| White Light Immunity | Exceptional resistance to interference from white light sources |
| Pet Immunity | Up to 25 kg (55 lbs), ideal for households with pets |
| Quad Linear Imaging Technology | Enables clear analysis of body dimensions, separating humans from pets and background objects |
| Advanced ASIC-based Electronics | For high reliability and performance |
| Installation | Height calibration free and adjustable PIR sensitivity |
| Package Availability | Available in packages of 6 (LC-100-PI-6PK) |
| Dimensions | 92 mm x 62.5 mm x 40 mm (3.62" x 2.46" x 1.57") |
| Weight | 58 g (2.04 oz) |
| Detection Method | Quad (Four Element) PIR |
| Power Input | 8.2 to 16 VDC |
| Current Draw (Standby) | 8 mA (5%) |
| Current Draw (Active) | 10 mA (5%) |
| Tamper Switch Contact Rating | 0.1 Amp @ 28 VDC |
| RFI Protection | 30 V/m, 10-1000 MHz |
| EMI Protection | 50,000 V |
