| Network Port | Poe (1~6): 10/100Mbps Poe ports (RJ45)
Poe (7~8): 10/100Mbps Poe ports, BT port, Compatible uplink ports (RJ45)
LAN: 10/100/1000Mbps uplink ports (RJ45) |
| Switch Capacity | 5.6 Gbps |
| Poe Standard | IEEE 802.3i 10 BASE-T
IEEE 802.3u 100 BASE-TX
IEEE 802.3ab 1000 BASE-TX
IEEE 802.3x Flow Control
IEEE 802.3af/at/bt Power over Ethernet |
| Transmission Distance | 1~130m |
| MAC Address List | 8K |
| Lightning Protection | 6KV |
| Poe Power Budget | 120W |
| ESD Protection | 8KV, Per: IEC61000-4-2 |
| Power Source | AC 180~240V, Total: ≤120W |
| Working Temperature | -30°C ~60°C |
| Humidity | 10%~90% (Non-condensing) |
| Storage Temperature | -40°C ~70°C |
| Storage Humidity | 5%~90% (Non-condensing) |
| Dimension | 187mm(L) x 139mm(W) x 43mm(H) |
| Weight | 0.86g |
