| Model No. | R-PL750D-FC0B-IN-V2 |
| Cables | Main Power Connector (20+4)Pin x 1 – 1PCS
CPU(4+4)Pin x 1– 2PCS
PCI-E(6+2)Pin x 1 – 1PCS
PCI-E(6+2)Pin x 2 – 1PCS
12V-2x6(16Pin) x 1 – 1PCS
SATA x 4 + 4Pin Peripheral x 1 – 2PCS |
| Type | ATX12V V3.0 |
| Product Dimensions | 150×140×86mm (W x L x H) |
| Efficiency Certification | 80Plus Bronze |
| Fan Size | 120mm |
| Fan Bearing | HYB (Hydro Bearing) |
| Topology | Active PFC+DC to DC |
| Capacitors | Chinese Electrolytic Capacitors |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms |
| Efficiency | ≥85% Under Typical Load (50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature | 0 - 40℃ |
| Regulatory | CE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B)/TUV-RH |
| Erp Regulation | ErP 2014 |
| Environment Protection | WEEE/中国 RoHS/Triman/P65 |
| MTBF | 100,000 Hours |
| Warranty | 5 Years |
