| Size | Desktop (with Mounting Kit) |
| Network Interface | 24 10/100/1000 BASE-T ports, 2 SFP |
| Standards | IEEE 802.3u, Fast Ethernet standards
IEEE 802.3af/at, Ethernet power supply POE standard
IEEE 802.3ab, Gigabit Ethernet standards
IEEE 802.3az, EEE, Energy efficient Ethernet standard
IEEE 802.3x, Full-duplex Ethernet data link layers
IEEE 802.3z, Gigabit Ethernet fiber-optic standard |
| Media Interface Exchange | Auto MDI/MDI-X adjustment on all ports |
| Lightning Protection | 6KV |
| Switching Fabric | 52 Gbps |
| Transmission Method | Adopt Store-and-forward |
| Data Transfer Rates | Gigabit Ethernet - 1000 Mbps, Ethernet - 100 Mbps |
| Physical Specifications | Dimensions (LxWxH): 440 x 180 x 44mm, Weight: 3.0kg |
| Poe Power Budget | 250W (30W max. per Poe port) |
| Power | Total Power: 250W |
| Humidity | Operating: 0% to 95% RH non-condensing, Storage: 0% to 95% RH non-condensing |
